Motive Installation

LVForce installs Motive hardware for trucking and commercial fleets in all 50 states: vehicle gateways, AI dashcams and asset gateways, installed at your terminals and confirmed reporting in your own Motive account before the truck goes back on the road. We are an independent installation contractor with no vendor affiliation — we do not resell Motive hardware or subscriptions. We do the physical work and prove it functions.

Motive fleets are usually regulated fleets, which changes the stakes. A tracker that goes offline on a landscaping van is an annoyance; an ELD that does not log is a compliance problem at a roadside inspection. That is why our install standard is built around verification, not just mounting.

The vehicle gateway is the backbone of a Motive deployment, providing GPS, engine diagnostics and the hours-of-service data path. On light-duty vans and pickups we connect at the OBD-II port; on Class 7 and Class 8 tractors we typically use a nine-pin J1939 connection; and where the port is occupied, inaccessible or exposed to tampering, we install an extension or hardwired harness and mount the gateway out of reach.

Every gateway is physically mounted rather than left hanging off a cable, with the run routed behind trim, secured away from pedals and steering shafts, loomed where it crosses metal edges, and left with a service loop so a future swap does not require cutting the harness. Installs on trucks that carry a second device — a legacy ELD, a customer-mandated tracker, a toll transponder — are planned so both units keep working instead of fighting for the same port.

An ELD deployment is not finished when the hardware is in — it is finished when the driver can actually log in. Where your rollout plan calls for it, we verify that the gateway pairs with the Motive driver app over Bluetooth from inside the cab, so you learn about a pairing problem in the yard instead of at a truck stop at 11 p.m.

We also leave the cab in a state a driver can work with: mount positions that do not block controls or vents, cable that does not swing into the driver's line of sight, and nothing left on the seat or floor. Where fleets want it, we provide a short in-cab orientation at handover covering where the device is, how to confirm it is connected, and who to call if it is not.

Multi-terminal deployments run as managed programs: one project manager, per-terminal waves with firm dates and vehicle lists, local crews in each market and VIN-level completion tracking. For trucking fleets we build the schedule around dispatch reality — overnight and weekend shifts, early-morning waves before drivers pull out, batch installs during a driver's 34-hour reset, or rolling batches of five to ten units a day.

Typical install time is 45 to 90 minutes per vehicle: about 30 to 45 minutes for a gateway plus road-facing camera on a light-duty unit, and 60 to 90 minutes for a tractor with a dual-facing dashcam and concealed routing. A two-technician crew usually completes 8 to 14 vehicles per day at one terminal, so a 150-truck fleet across four terminals is normally finished in three to four weeks.

Motive installation is priced per vehicle, driven by four factors: the hardware set (gateway alone versus gateway plus dual-facing dashcam), vehicle class and how difficult the cab is to route, how many trucks are staged at one terminal, and travel to remote or low-count yards.

Volume at a single site is the dominant lever because mobilization is the fixed cost — thirty tractors at one terminal costs far less per unit than six at five sites. National programs are quoted as a program with a blended per-vehicle rate and a defined wave schedule, so you budget one number rather than absorbing a stream of service invoices. LVForce is licensed and insured nationwide, with certificates of insurance provided on request.
